Heat Pump Water Heater

005-11-12200002371_cf20121026003img_0323lsq02rclsq03rlsq05r-3lsq10rlsq20-25rp1010554
NextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnailNextGen ScrollGallery thumbnail

Heat pumps Water Heater is a revolutionary way to heat domestic hot water, it also called “Hot Water Heat Pump”. By converting the heat from surrounding air to hot water in your water tank, they are usually three times more efficient than electric resistance water heaters–meaning that they can produce the same amount of hot water for one-third the amount of electricity.

Features of SIRAC heat pump water heater:

  • High-efficiency, Up to 75% energy saving, compared with conventional water heaters such as gas/oil boilers and electricity resistance water heaters.
  • Powder coated steel plate (stainless steel cabinet available)
  • LCD display control panel
  • Automatic unit on/off timer clock
  • Insufficient water flow protection
  • High/Low pressure protection
  • Automatic reversing defrosting function enables units to work reliably in chilling climate.
  • Suitable for water heating from small families to huge commercial premises such as hotel, hospital, college, factory, washing room and sauna center etc.

For years SIRAC is listed as top heat pump water heater brand in China market, and we offer a large variety of HPWH models from 7KW to 90KW.

Sirac Heat Pump Water Heater Technical Specifications

Model LSQ02RF LSQ03RF LSQ05RF LSQ06RF LSQ08RF LSQ10RF LSQ15RF LSQ20RF LSQ25RF
Outlet Water Rated Temp(℃) 55
Outlet Water Max. Temp(℃) 65
Heating Capacity(KW)  7 11.5 19 23 30 38 46 75 90
Rated Power Input(KW)  1.7 2.8 4.6 5.6 7.4 9.3 11.2 17.4 21.2
Power Supply (V/PH/HZ) 220/1/50 220(380)/1(3)/50 380/3/50
Compressor Type Highly Invotech Scroll
Compressor Qty 1 1 1 1 2 2 2 2 2
Cabinet Material  Powder Coated Galvanized Steel Cabinet / 304 Stainless Steel Cabinet
Air Discharge Horizontal Vertical
Gas Flow Restriction  Electronic Expansion Valve
Defrosting Device Yes
Heat Exchanger Type Copper tube in tube
Refrigerant Type R407C
Approx.Water Output (liters/h) 190 280 468 567 751 936 1133 1847 2143
Noise Level dB(A) 49 51 53 54 57 58 58 63 63
Pipe size (inch) 3/4″ 1″ 1.25″ 2.5″
Package Dimensions(mm) Length 990 750 750 800 1484 1420 2010 2010
Width 450 690 690 750 730 725 1118 1118
Height 560 845 1060 1080 1060 1365 1797 1904
Net Weight(kg) 79 115 150 175 255 280 360 630 780

Advantages of SIRAC Products:

  1. High quality famous brand components in SIRAC Heat Pumps:
  2. Dozens system protections to ensure safe operation and long lifespan.SIRAC heat pumps come with insufficient water flow protection, high/low pressure protection, phase sequence protection, overload protection, anti freeze protection, discharge gas over-temperature protection, automatic defrost function and parameter setting function. These protections and functions enable the heat pumps to operate safely and reliably.The units also have power down memory function. Once the units have been installed, human attendance is almost unnecessary.
  3. Key Benefits :

     a. fast hot water recovery at temperatures up to 60°C

     b. uses up to 70% less household energy, freeing up power for other appliances and costing you less

     c. quiet operation, with no unsightly solar collectors on the roof

     d. compact and easy to install plug in system – operates with standard high pressure or low pressure            geysers or storage cylinders

     e. can be retro-fitted to existing geysers and boilers

     f. can be used in conjunction with solar heaters

     g. fully automatic control with adjustable water temperature setting

     h. environmentally responsible – extremely energy efficient, with no Greenhouse Gas emissions
